ZL轉鼓造粒機
| 規格型號 |
產量 （t/h） |
筒體轉速 | 筒體斜度 | 主電機 | 主減速機 |
重量 (kw) |
|
| 型號 | 功率 | ||||||
| 1.4×4.0 | 4.0-80 | 13.2 | 2.0° | Y160M-6 | 7.5 | JZQ400 | 8000 |
| 1.4×6.0 | 4.0-8.0 | 13.2 | 2.0° | Y160M-6 | 7.5 | JZQ400 | 9000 |
| 1.6×4.0 | 5.0-10 | 12.0 | 2.5° | Y160L-6 | 11.0 | ZLY125-12.5 | 10000 |
| 1.6×6.0 | 5.0-10 | 12.0 | 2.5° | Y160L-6 | 11.0 | ZLY125-12.5 | 11000 |
| 1.8×6.0 | 6.0-12 | 8.2 | 2.5° | Y180M-4 | 15.0 | ZSY200-22.4 | 16000 |
| 1.8×8.0 | 8.0-16 | 8.2 | 2.5° | Y200L-6 | 22.0 | ZL60-25 | 17600 |
| 2.0×6.0 | 10-20 | 10.5 | 2.5° | Y180L-4 | 30.0 | ZL60-25 | 21800 |
| 2.0×8.0 | 12-24 | 11.0 | 2.5° | Y180L-4 | 30.0 | ZL60-25 | 25800 |
| 2.2×6.0 | 15-30 | 11.0 | 2.5° | Y180L-4 | 30.0 | ZL60-25 | 25500 |
| 2.2×8.0 | 18-35 | 11.0 | 2.5° | Y200M-6 | 37.0 | ZLY75-20 | 28200 |
| 2.4×7.0 | 19-40 | 8.6 | 3.5% | Y250M-6 | 37.0 | ZLY250 | 35200 |
| 2.4×8.0 | 20-40 | 9.7 | 3.5% | Y280M-6 | 55.0 | ZL65-25 | 39200 |
| 2.6×6.0 | 22-50 | 9.7 | 2.5° | Y250M-6 | 37.0 | ZLY250 | 36800 |
| 2.6×8.0 | 25-50 | 8.8 | 2.5° | Y280M-6 | 55.0 | ZSY224-25 | 40600 |
| 2.8×8.0 | 30-60 | 5.2 | 3.5% | Y315M-6 | 90.0 | ZSY280-22.4 | 52600 |
| 2.8×10 | 40-80 | 5.2 | 3.5% | Y315M-6 | 90.0 | ZSY315-25 | 58500 |
| 3.0×8.0 | 40-80 | 8.8 | 2.5° | Y315M-6 | 90.0 | ZSY315-16 | 59400 |
| 3.0×10 | 45-90 | 9.17 | 2.5° | Y315L-6 | 110 | ZLY280-31.5 | 69500 |
| 3.2×8.0 | 40-80 | 11.0 | 2.5° | Y315L-6 | 110 | ZLY280-31.5 | 70000 |
| 3.2×10 | 45-90 | 11.0 | 2.5° | Y315L-6 | 110 | ZLY280-31.5 | 74200 |
| 3.4×8.0 | 50-100 | 9.14 | 2.5° | Y315L1-4 | 160 | ZLY315-20 | 80000 |
| 3.4×10 | 55-110 | 9.14 | 2.5° | Y315L1-4 | 160 | ZLY315-20 | 82800 |
| 3.7×8.0 | 70-140 | 11.0 | 2.5° | Y315M-4 | 185 | ZSY355-20 | 92500 |
2、造粒物料溫度：45-80℃；
3、生產能力由于產品的組成分不同及工藝條件的不同而變化
